Panic in ZFS during zfs recv (while snapshots being destroyed)
Karl Denninger
karl at denninger.net
Tue Oct 20 15:51:19 UTC 2015
More data on this crash from this morning; I caught it in-process this
time and know exactly where it was in the backup script when it detonated.
Here's the section of the script that was running when it blew up:
for i in $ZFS
do
echo Processing $i
FILESYS=`echo $i|cut -d/ -f2`
zfs list $i at zfs-base >/dev/null 2>&1
result=$?
if [ $result -eq 1 ];
then
echo "Make and send zfs-base snapshot"
zfs snapshot -r $i at zfs-base
zfs send -R $i at zfs-base | zfs receive -Fuvd $BACKUP
else
base_only=`zfs get -H com.backup:base-only $i|grep true`
result=$?
if [ $result -eq 1 ];
then
echo "Bring incremental backup up to date"
old_present=`zfs list $i at zfs-old >/dev/null 2>&1`
old=$?
if [ $old -eq 0 ];
then
echo "Previous incremental sync was
interrupted; resume"
else
zfs rename -r $i at zfs-base $i at zfs-old
zfs snapshot -r $i at zfs-base
fi
zfs send -RI $i at zfs-old $i at zfs-base | zfs
receive -Fudv $BACKUP
result=$?
if [ $result -eq 0 ];
then
zfs destroy -r $i at zfs-old
zfs destroy -r $BACKUP/$FILESYS at zfs-old
else
echo "STOP - - ERROR RUNNING COPY on $i!!!!"
exit 1
fi
else
echo "Base-only backup configured for $i"
fi
fi
echo
done
And the output on the console when it happened:
Begin local ZFS backup by SEND
Run backups of default [zsr/R/10.2-STABLE zsr/ssd-txlog zs/archive
zs/colo-archive zs/disk zs/pgsql zs/pics dbms/ticker]
Tue Oct 20 10:14:09 CDT 2015
Import backup pool
Imported; ready to proceed
Processing zsr/R/10.2-STABLE
Bring incremental backup up to date
_*Previous incremental sync was interrupted; resume*_
attempting destroy backup/R/10.2-STABLE at zfs-auto-snap_daily-2015-10-13-00h07
success
attempting destroy
backup/R/10.2-STABLE at zfs-auto-snap_hourly-2015-10-18-12h04
success
*local fs backup/R/10.2-STABLE does not have fromsnap (zfs-old in stream);**
**must have been deleted locally; ignoring*
receiving incremental stream of
zsr/R/10.2-STABLE at zfs-auto-snap_daily-2015-10-18-00h07 into
backup/R/10.2-STABLE at zfs-auto-snap_daily-2015-10-18-00h07
snap backup/R/10.2-STABLE at zfs-auto-snap_daily-2015-10-18-00h07 already
exists; ignoring
received 0B stream in 1 seconds (0B/sec)
receiving incremental stream of
zsr/R/10.2-STABLE at zfs-auto-snap_weekly-2015-10-18-00h14 into
backup/R/10.2-STABLE at zfs-auto-snap_weekly-2015-10-18-00h14
snap backup/R/10.2-STABLE at zfs-auto-snap_weekly-2015-10-18-00h14 already
exists; ignoring
received 0B stream in 1 seconds (0B/sec)
receiving incremental stream of zsr/R/10.2-STABLE at zfs-base into
backup/R/10.2-STABLE at zfs-base
snap backup/R/10.2-STABLE at zfs-base already exists; ignoring
That bolded pair of lines should _*not*_ be there. It means that the
snapshot "zfs-old" is on the source volume, but it shouldn't be there
because after the copy is complete we destroy it on both the source and
destination. Further, when it is attempted to be sent while the
snapshot name (zfs-old) was found in a zfs list /*the data allegedly
associated with the phantom snapshot that shouldn't exist was not there
*/(second bolded line)
zfs send -RI $i at zfs-old $i at zfs-base | zfs
receive -Fudv $BACKUP
result=$?
if [ $result -eq 0 ];
then
*zfs destroy -r $i at zfs-old**
** zfs destroy -r $BACKUP/$FILESYS at zfs-old*
else
echo "STOP - - ERROR RUNNING COPY on $i!!!!"
exit 1
fi
I don't have the trace from the last run (I didn't save it) *but there
were no errors returned by it *as it was run by hand (from the console)
while I was watching it.
This STRONGLY implies that the zfs destroy /allegedly /succeeded (it ran
without an error and actually removed the snapshot) but left the
snapshot _*name*_ on the volume as it was able to be found by the
script, and then when that was referenced by the backup script in the
incremental send the data set was invalid producing the resulting panic.
The bad news is that the pool shows no faults and a scrub which took
place a few days ago says the pool is fine. If I re-run the backup I
suspect it will properly complete (it always has in the past as a resume
from the interrupted one) but clearly, whatever is going on here looks
like some sort of race in the destroy commands (which _*are*_ being run
recursively) that leaves the snapshot name on the volume but releases
the data stored in it, thus the panic when it is attempted to be
referenced.
I have NOT run a scrub on the pool in an attempt to preserve whatever
evidence may be there; if there is something that I can look at with zdb
or similar I'll leave this alone for a bit -- the machine came back up
and is running fine.
This is a production system but I can take it down off-hours for a short
time if there is a need to run something in single-user mode using zdb
to try to figure out what's going on. There have been no known hardware
issues with it and all the other pools (including the ones on the same
host adapter) are and have been running without incident.
Ideas?
Fatal trap 12: page fault while in kernel mode
cpuid = 9; apic id = 21
fault virtual address = 0x378
fault code = supervisor read data, page not present
instruction pointer = 0x20:0xffffffff80940ae0
stack pointer = 0x28:0xfffffe0668018680
frame pointer = 0x28:0xfffffe0668018700
code segment = base 0x0, limit 0xfffff, type 0x1b
= DPL 0, pres 1, long 1, def32 0, gran 1
processor eflags = interrupt enabled, resume, IOPL = 0
current process = 70921 (zfs)
trap number = 12
panic: page fault
cpuid = 9
KDB: stack backtrace:
db_trace_self_wrapper() at db_trace_self_wrapper+0x2b/frame
0xfffffe0668018160
kdb_backtrace() at kdb_backtrace+0x39/frame 0xfffffe0668018210
vpanic() at vpanic+0x126/frame 0xfffffe0668018250
panic() at panic+0x43/frame 0xfffffe06680182b0
trap_fatal() at trap_fatal+0x36b/frame 0xfffffe0668018310
trap_pfault() at trap_pfault+0x2ed/frame 0xfffffe06680183b0
trap() at trap+0x47a/frame 0xfffffe06680185c0
calltrap() at calltrap+0x8/frame 0xfffffe06680185c0
--- trap 0xc, rip = 0xffffffff80940ae0, rsp = 0xfffffe0668018680, rbp =
0xfffffe0668018700 ---
*__mtx_lock_sleep() at __mtx_lock_sleep+0x1b0/frame 0xfffffe0668018700**
**dounmount() at dounmount+0x58/frame 0xfffffe0668018780**
**zfs_unmount_snap() at zfs_unmount_snap+0x114/frame 0xfffffe06680187a0**
**dsl_dataset_user_release_impl() at
dsl_dataset_user_release_impl+0x103/frame 0xfffffe0668018920**
**dsl_dataset_user_release_onexit() at
dsl_dataset_user_release_onexit+0x5c/frame 0xfffffe0668018940**
**zfs_onexit_destroy() at zfs_onexit_destroy+0x56/frame 0xfffffe0668018970**
**zfsdev_close() at zfsdev_close+0x52/frame 0xfffffe0668018990*
devfs_fpdrop() at devfs_fpdrop+0xa9/frame 0xfffffe06680189b0
devfs_close_f() at devfs_close_f+0x45/frame 0xfffffe06680189e0
_fdrop() at _fdrop+0x29/frame 0xfffffe0668018a00
closef() at closef+0x21e/frame 0xfffffe0668018a90
closefp() at closefp+0x98/frame 0xfffffe0668018ad0
amd64_syscall() at amd64_syscall+0x35d/frame 0xfffffe0668018bf0
Xfast_syscall() at Xfast_syscall+0xfb/frame 0xfffffe0668018bf0
--- syscall (6, FreeBSD ELF64, sys_close), rip = 0x801a01f5a, rsp =
0x7fffffffd1e8, rbp = 0x7fffffffd200 ---
Uptime: 5d0h58m0s
On 10/15/2015 09:27, Karl Denninger wrote:
> Got another one of these this morning, after a long absence...
>
> Same symptom -- happened during a backup (send/receive) and it's in
> the same place -- when the snapshot is unmounted. I have a clean dump
> and this is against a quite-recent checkout, so the
> most-currently-rolled forward ZFS changes are in this kernel.
>
>
> Fatal trap 12: page fault while in kernel mode
> cpuid = 14; apic id = 34
> fault virtual address = 0x378
> fault code = supervisor read data, page not present
> instruction pointer = 0x20:0xffffffff80940ae0
> stack pointer = 0x28:0xfffffe066796c680
> frame pointer = 0x28:0xfffffe066796c700
> code segment = base 0x0, limit 0xfffff, type 0x1b
> = DPL 0, pres 1, long 1, def32 0, gran 1
> processor eflags = interrupt enabled, resume, IOPL = 0
> current process = 81187 (zfs)
> trap number = 12
> panic: page fault
> cpuid = 14
> KDB: stack backtrace:
> db_trace_self_wrapper() at db_trace_self_wrapper+0x2b/frame
> 0xfffffe066796c160
> kdb_backtrace() at kdb_backtrace+0x39/frame 0xfffffe066796c210
> vpanic() at vpanic+0x126/frame 0xfffffe066796c250
> panic() at panic+0x43/frame 0xfffffe066796c2b0
> trap_fatal() at trap_fatal+0x36b/frame 0xfffffe066796c310
> trap_pfault() at trap_pfault+0x2ed/frame 0xfffffe066796c3b0
> trap() at trap+0x47a/frame 0xfffffe066796c5c0
> calltrap() at calltrap+0x8/frame 0xfffffe066796c5c0
> --- trap 0xc, rip = 0xffffffff80940ae0, rsp = 0xfffffe066796c680, rbp
> = 0xfffffe
> 066796c700 ---
> __mtx_lock_sleep() at __mtx_lock_sleep+0x1b0/frame 0xfffffe066796c700
> dounmount() at dounmount+0x58/frame 0xfffffe066796c780
> zfs_unmount_snap() at zfs_unmount_snap+0x114/frame 0xfffffe066796c7a0
> dsl_dataset_user_release_impl() at
> dsl_dataset_user_release_impl+0x103/frame 0xf
> ffffe066796c920
> dsl_dataset_user_release_onexit() at
> dsl_dataset_user_release_onexit+0x5c/frame
> 0xfffffe066796c940
> zfs_onexit_destroy() at zfs_onexit_destroy+0x56/frame 0xfffffe066796c970
> zfsdev_close() at zfsdev_close+0x52/frame 0xfffffe066796c990
> devfs_fpdrop() at devfs_fpdrop+0xa9/frame 0xfffffe066796c9b0
> devfs_close_f() at devfs_close_f+0x45/frame 0xfffffe066796c9e0
> _fdrop() at _fdrop+0x29/frame 0xfffffe066796ca00
> closef() at closef+0x21e/frame 0xfffffe066796ca90
> closefp() at closefp+0x98/frame 0xfffffe066796cad0
> amd64_syscall() at amd64_syscall+0x35d/frame 0xfffffe066796cbf0
> Xfast_syscall() at Xfast_syscall+0xfb/frame 0xfffffe066796cbf0
> --- syscall (6, FreeBSD ELF64, sys_close), rip = 0x801a01f5a, rsp =
> 0x7fffffffd728, rbp = 0x7fffffffd740 ---
> Uptime: 3d15h37m26s
>
>
> On 8/27/2015 15:44, Karl Denninger wrote:
>> No, but that does sound like it might be involved.....
>>
>> And yeah, this did start when I moved the root pool to a mirrored pair
>> of Intel 530s off a pair of spinning-rust WD RE4s.... (The 530s are darn
>> nice performance-wise, reasonably inexpensive and thus very suitable for
>> a root filesystem drive and they also pass the "pull the power cord"
>> test, incidentally.)
>>
>> You may be onto something -- I'll try shutting it off, but due to the
>> fact that I can't make this happen and it's a "every week or two" panic,
>> but ALWAYS when the zfs send | zfs recv is running AND it's always on
>> the same filesystem it will be a fair while before I know if it's fixed
>> (like over a month, given the usual pattern here, as that would be 4
>> "average" periods without a panic).....
>>
>> I also wonder if I could tune this out with some of the other TRIM
>> parameters instead of losing it entirely.
>>
>> vfs.zfs.trim.max_interval: 1
>> vfs.zfs.trim.timeout: 30
>> vfs.zfs.trim.txg_delay: 32
>> vfs.zfs.trim.enabled: 1
>> vfs.zfs.vdev.trim_max_pending: 10000
>> vfs.zfs.vdev.trim_max_active: 64
>> vfs.zfs.vdev.trim_min_active: 1
>>
>> That it's panic'ing on a mtx_lock_sleep might point this way.... the
>> trace shows it coming from a zfs_onexit_destroy, which ends up calling
>> zfs_unmount_snap() and then it blows in dounmount() while executing
>> mtx_lock_sleep().
>>
>> I do wonder if I'm begging for new and innovative performance issues if
>> I run with TRIM off for an extended period of time, however..... :-)
>>
>>
>> On 8/27/2015 15:30, Sean Chittenden wrote:
>>> Have you tried disabling TRIM? We recently ran in to an issue where a `zfs delete` on a large dataset caused the host to panic because TRIM was tripping over the ZFS deadman timer. Disabling TRIM worked as valid workaround for us. ? You mentioned a recent move to SSDs, so this can happen, esp after the drive has experienced a little bit of actual work. ? -sc
>>>
>>>
>>> --
>>> Sean Chittenden
>>> sean at chittenden.org
>>>
>>>
>>>> On Aug 27, 2015, at 13:22, Karl Denninger <karl at denninger.net> wrote:
>>>>
>>>> On 8/15/2015 12:38, Karl Denninger wrote:
>>>>> Update:
>>>>>
>>>>> This /appears /to be related to attempting to send or receive a
>>>>> /cloned /snapshot.
>>>>>
>>>>> I use /beadm /to manage boot environments and the crashes have all
>>>>> come while send/recv-ing the root pool, which is the one where these
>>>>> clones get created. It is /not /consistent within a given snapshot
>>>>> when it crashes and a second attempt (which does a "recovery"
>>>>> send/receive) succeeds every time -- I've yet to have it panic twice
>>>>> sequentially.
>>>>>
>>>>> I surmise that the problem comes about when a file in the cloned
>>>>> snapshot is modified, but this is a guess at this point.
>>>>>
>>>>> I'm going to try to force replication of the problem on my test system.
>>>>>
>>>>> On 7/31/2015 04:47, Karl Denninger wrote:
>>>>>> I have an automated script that runs zfs send/recv copies to bring a
>>>>>> backup data set into congruence with the running copies nightly. The
>>>>>> source has automated snapshots running on a fairly frequent basis
>>>>>> through zfs-auto-snapshot.
>>>>>>
>>>>>> Recently I have started having a panic show up about once a week during
>>>>>> the backup run, but it's inconsistent. It is in the same place, but I
>>>>>> cannot force it to repeat.
>>>>>>
>>>>>> The trap itself is a page fault in kernel mode in the zfs code at
>>>>>> zfs_unmount_snap(); here's the traceback from the kvm (sorry for the
>>>>>> image link but I don't have a better option right now.)
>>>>>>
>>>>>> I'll try to get a dump, this is a production machine with encrypted swap
>>>>>> so it's not normally turned on.
>>>>>>
>>>>>> Note that the pool that appears to be involved (the backup pool) has
>>>>>> passed a scrub and thus I would assume the on-disk structure is ok.....
>>>>>> but that might be an unfair assumption. It is always occurring in the
>>>>>> same dataset although there are a half-dozen that are sync'd -- if this
>>>>>> one (the first one) successfully completes during the run then all the
>>>>>> rest will as well (that is, whenever I restart the process it has always
>>>>>> failed here.) The source pool is also clean and passes a scrub.
>>>>>>
>>>>>> traceback is at http://www.denninger.net/kvmimage.png; apologies for the
>>>>>> image traceback but this is coming from a remote KVM.
>>>>>>
>>>>>> I first saw this on 10.1-STABLE and it is still happening on FreeBSD
>>>>>> 10.2-PRERELEASE #9 r285890M, which I updated to in an attempt to see if
>>>>>> the problem was something that had been addressed.
>>>>>>
>>>>>>
>>>>> --
>>>>> Karl Denninger
>>>>> karl at denninger.net <mailto:karl at denninger.net>
>>>>> /The Market Ticker/
>>>>> /[S/MIME encrypted email preferred]/
>>>> Second update: I have now taken another panic on 10.2-Stable, same deal,
>>>> but without any cloned snapshots in the source image. I had thought that
>>>> removing cloned snapshots might eliminate the issue; that is now out the
>>>> window.
>>>>
>>>> It ONLY happens on this one filesystem (the root one, incidentally)
>>>> which is fairly-recently created as I moved this machine from spinning
>>>> rust to SSDs for the OS and root pool -- and only when it is being
>>>> backed up by using zfs send | zfs recv (with the receive going to a
>>>> different pool in the same machine.) I have yet to be able to provoke
>>>> it when using zfs send to copy to a different machine on the same LAN,
>>>> but given that it is not able to be reproduced on demand I can't be
>>>> certain it's timing related (e.g. performance between the two pools in
>>>> question) or just that I haven't hit the unlucky combination.
>>>>
>>>> This looks like some sort of race condition and I will continue to see
>>>> if I can craft a case to make it occur "on demand"
>>>>
>>>> --
>>>> Karl Denninger
>>>> karl at denninger.net <mailto:karl at denninger.net>
>>>> /The Market Ticker/
>>>> /[S/MIME encrypted email preferred]/
>>> %SPAMBLOCK-SYS: Matched [+Sean Chittenden <sean at chittenden.org>], message ok
>>>
>
> --
> Karl Denninger
> karl at denninger.net <mailto:karl at denninger.net>
> /The Market Ticker/
> /[S/MIME encrypted email preferred]/
--
Karl Denninger
karl at denninger.net <mailto:karl at denninger.net>
/The Market Ticker/
/[S/MIME encrypted email preferred]/
-------------- next part --------------
A non-text attachment was scrubbed...
Name: smime.p7s
Type: application/pkcs7-signature
Size: 2996 bytes
Desc: S/MIME Cryptographic Signature
URL: <http://lists.freebsd.org/pipermail/freebsd-fs/attachments/20151020/90cde46a/attachment.bin>
More information about the freebsd-fs
mailing list
